Xprinter XP-DT325B

Xprinter XP-DT325B

Regular price LE 1,750.00 EGP
Regular price Sale price LE 1,750.00 EGP
Sale Sold out

 Model

XP-DT325B

Printing Features

Resolution 203 DPI
Printing method Direct Thermal
Max.print speed 152 mm/s Max.
Max.print width 80mm (3.15")
Max.print length 1778 mm (70")

Media

Media type Continuous, gap, black mark, fan-fold and punched hole
Media width 20 ~ 82 mm (0.78 " ~ 3.2 ")
Media thickness 0.06 ~ 0.20 mm
Media core diameter 25.4 ~ 76.2 mm (1 "~ 3 ")
Label length 10 ~ 1778 mm (0.39 " ~ 70 ")
Label roll capacity 80mm (3.15")

Performance Features

Processor

32-bit CPU

Memory

8MB Flash Memory/8MB SDRAM

Interface

Standard: USB  Optional:WIFI/Bluetooth

Sensors

Gap sensor
Cover opening sensor
Black mark sensor

Fonts/Graphics/Symbologies

Internal fonts

8 alpha-numeric bitmap fonts, Windows fonts are downloadable from software.

1D barcode

Code 39, Code 93, Code 128UCC, Code 128 ,subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on,
MSI, PLESSEY, POSTNET, China POST

2D barcode PDF-417, Maxicode, DataMatrix, QR code
Rotation
0°、90°、180°、270°
Emulaion TSPL、EPL、ZPL、DPL、ESC、POS

Physical Features

Dimension 187(D) x 162(W) x146(H)mm
Weight 1.1kg

Reliability

Print head life 30 km

Software

Driver Windows/Linux/Mac
SDK Windows/Android/iOS

Power adaptor

Input AC 100-240V, 50-60Hz
Output DC 24V, 2.5A, 60W

Options

Factory Options ①WIFI
②Bluetooth
Dealer Options ①External paper roll holder and 1 "paper roll
②Extension board for external paper roll holder
③Shipment waybill box



PRODUCT WARRANTY: 1YEAR

Xprinter XP-DT325B -Pdf
