XP-426B
XP-426B
Call Us For Price: 01093596600
Specifications:
| Printer Specifications | |
| Resolution | 203DPI |
|
Print Method |
Thermal Transfer / Direct Thermal |
| Memory | 8 MB RAM / 8 MB Flash |
| Max.Print Width | 4.09 in./ 104 mm |
| Max.Print Speed | Up to 5 ips. (127 mm/s) |
| Media Sensors | Movable Black Mark Sensor / Movable Gap Sensor |
| Emulation | TSPL, ZPL, EPL, DPL |
| Interface | USB |
| Others | Optional RTC, Standard SD Card Slot |
|
Media and Ribbon Characteristics |
|
|
Media Length |
0.39 in.~70 in. (10 mm ~ 1778 mm) |
|
Media Width |
1 in. ~ 4.6 in. (25.4 mm ~ 118 mm) |
|
Media Roll Size |
5 in. / 127 mm Outer Diameter, Core Inner Diameter: 1 in. (25.4 mm) |
|
Media Thickness |
0.0023 in. (0.06 mm) Min.; 0.01 in. (0.254 mm) Max. |
|
Media Types |
Continuous, Gap, Black mark, Fanfold, Perforated Media |
| Ribbon Outside Diameter | 2.63 in. / 67 mm |
| Max. Ribbon Length | 300 Meters (984 ft.) |
| Ribbon Width | 1 in. ~ 4.3 in. (25.4 mm ~ 110 mm) |
| Ribbon Core I.D. | 1 in. / 25.4 mm |
|
Environment Condition |
|
|
Operating Temp. |
5~40℃ (41~104℉) |
|
Storage Temp. |
-40~60℃ (-40~140℉) |
|
Operating Humidity |
25 ~ 85% non-condensing |
|
Storage Humidity |
10 ~ 90% non-condensing |
|
Fonts/Graphics/Symbologies |
|
|
1D Bar Codes |
Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Coda bar, Interleaved 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 Data bar, Code 11 |
|
2D Bar Codes |
PDF-417, Maxi code, Data Matrix, QR code, Aztec |
|
Fonts and Graphics |
Font 0 ~ Font 8 |
|
Software |
|
|
Driver |
Windows /Linux /Mac / Android / Chrome OS |
|
SDK |
Windows/Linux / Android /iOS |
|
Software |
Bartender Ultra Lite / Mobile Label Design App |
|
Accessories |
|
|
Standard Accessories |
Power Adapter, Power Cord, USB Cable, User Manual, CD, Label spindle, Fixing tab, Fixing tab, Ribbon spindle, Ribbon for test, Ribbon paper core, label roll for test |
|
Factory Installed Options |
Bluetooth Module, Wi-Fi Module, Peel-off Module, Cutter Module |
|
User Options |
8" External Paper Roll Holder |
|
Product Warranty |
|
|
Printhead life |
The earlier of 30 km usage or 1 year |
|
Platen roller life |
The earlier of 30 km usage or 1 year |
|
Warranty |
1 Year |
|
Physical Characteristics |
|
|
Dimension |
299 mm x 235 mm x 198.3 mm (D x W x H) |
|
Weight |
2.55 Kg |
