TM-T 20X Lan

Epson TM-T20X Network

PRINT SPECIFICATIONS:

• Print method:- Line Thermal
• Dot density:- 203 dpi x 203 dpi
• Print speed Max.:- 200mm/s
• Print width (80mm paper width):- 72mm ±0.5mm
• Fonts:- 12x24 (Font A), 9x17 (Font B)
• Column capacity (80mm paper width):- 48 (Font A), 64 (Font B)
• Character size:- 1.25x3 mm (Font A), 0.88x2.13 mm (Font B)
• Character set:- Alphanumeric 95, International character 18 set, Graphics 128x43page
• Characters:- ANK
• Barcode:- UPC-A, UPC-E, JAN8/EAN 8, JAN13/EAN13, Code39, Code93, Code128, ITF, CODABAR(NW-7), GS1-128, GS1 DataBar Omnidirectional, GS1 DataBar Truncated, GS1 DataBar Limited, GS1 DataBar Expanded
• 2-Dimensional Symbols:- PDF417, QR code, Maxi Code, Two-dimensional GS1 DataBar, Composite Symbology
• Paper size (80mm paper width):- 79.5±0.5mm
• Diameter:- 83mm
• Paper thickness:- 53-75 μm
• Auto cutter:- Partial cut (one point in center left uncut)
• Sensors:- Roll paper end, Cover open
• MCBF:- 60 million lines
• MTBF:- 360,000 hours
• Auto cutter life:- 1.5 million cuts
• Head life:- 100km, 15 million lines
• Interface:- RS-232C; Ethernet
• D.K.D functions:- 2 drivers
• AC adapter:- Embedded
• Power source:- AC100~240V, 50~60Hz
• Stand-by:- Approx. 27.8 W
• Receipt printing:- Approx. 0.4W
• Noise level:- Approx. 55 dB (bystander position)
• Overall Dimensions:- 140 mm (W) x 192 mm (D) x 137 mm (H)
• Weight [kg]:- Approx. 1.5kg
• Operating systems:- Windows, MacOSX, iOS, Android, Linux

PRODUCT WARRANTY: 1YEAR
